Insulation: Cross-Linked Polyethylene (XLPE), Type RU90
Jacket: Polyvinyl Chloride (PVC)
Colur Coding: Insulation - Black ,White or Red ,
Jacket - Black or others upon request
Bonding Conductor (Ground): One(1) bare solid or standed copper conductor
File Listing No.: 300938
Application:
· For open or concealed wiring in wet, damp or dry locations, including direct burial in earth where not exposed to mechanical injury.
· Maximum conductor temperature 60°C.
· Suitable for outdoor and underground installation, with sunlight and moisture resistance.
· Minimum recommended handling temperature minus 25°C.
Features:
· Two or three copper conductors with 60ºC PVC insulation.
· Bare bonding conductor and overall black PVC jacket with sunlight, moisture and crush resistance.
· Rated 300 volts. LEAD FREE and RoHS compliant.
Compliances: CSA C22.2 No. 48
CSA C22.2 No. 38
CSA C22.2 No. 2556
FT1 Vertical Propagation Flame Test
RoHS
