Conductor: Solid bare copper (ASTM B3), 22 AWG, 2–12 cores
Insulation: Color-coded PE or PVC
Jacket: PVC (black/white, or custom)
Voltage: 300V
Temp Rating: -40°C to 80°C
Flame Rating: CSA FT4, UL 70,000 BTU
File Listing No.: 300938
Application：
Low-voltage communication cable for indoor/riser wiring (CMR/CMG). Suitable for telephone lines, security systems, intercoms, and Class 2 control circuits. Supports data/audio transmission in residential, commercial, and light industrial environments.
Features：
- · Solid copper for stable signal & low resistance
- · PE/PVC insulation + PVC jacket: moisture/corrosion resistant
- · Color-coded cores for easy identification
- · Riser-rated (CMR/FT4) for vertical shaft installation
- · Exposed/concealed/raceway wiring (dry/damp areas)
Compliances：
- · CSA C22.2 No.214 (ZSW/CMG)
- · UL 444 (CM/CMR)
- · UL 1666 / CSA FT4
- · RoHS Compliant
